All packages

host_uniswap_v3

hostel
v0.2.11/22 downloads/Repository

Package ref

host-uniswap-v3@v0.2.11
Download .spkg

Run package

CLI

Run graph_out from the command line.

substreams run host-uniswap-v3@v0.2.11 graph_out -e mainnet
Authenticate by running substreams auth or directly on thegraph.market (see docs).

README

Uniswap v3 Substreams package

Substreams Package Open in DevPod! Open in GitHub Codespaces

Substreams-based Uniswap-v3 Substreams-powered-subgraph.

This module emits EntityChanges, and are written directly to graph-node without any AssemblyScript mappings therein.

This module covers all of the entities of the original v3-subgraph by the Uniswap team. It syncs much faster.

Launch the devpod above and run:

substreams auth
substreams build
substreams gui

Alternatively, run the graph_out module against a Substreams cluster, without building it locally:

substreams run -t +150 uniswap-v3@latest graph_out
[...]
{
  "@module": "graph_out",
  "@block": 12369621,
  "@type": "sf.substreams.entity.v1.EntityChanges",
  "@data": {
    "entityChanges": [
      {
        "entity": "Factory",
        "id": "1f98431c8ad98523631ae4a59f267346ea31f984",
        "ordinal": "1",
        "operation": "CREATE",
        "fields": [
          {
            "name": "id",
            "newValue": {
              "string": "1f98431c8ad98523631ae4a59f267346ea31f984"
            }
          },
          {
            "name": "poolCount",
            "newValue": {
              "bigint": "0"
            }
          },
[...]
       ]
      },
     {
        "entity": "Pool",
        "id": "1d42064fc4beb5f8aaf85f4617ae8b3b5b8bd801",
        "ordinal": "927",
        "operation": "UPDATE",
        "fields": [
          {
            "name": "totalValueLockedToken0",
            "newValue": {
              "bigdecimal": "0.9999999999999999240000000000003427709097170609759698726797493006923644998096278868615627288818359375"
            },
            "oldValue": {
              "bigdecimal": "0"
            }
          }
        ]
      },
[...]
    ]
  }
}

Hack on it

Build substreams-uniswap-v3

make build
[...]
substreams run  -e mainnet.eth.streamingfast.io:443 substreams.yaml graph_out -t +150
[...]
try it :)

Pack everything to release

substreams pack substreams.yaml

Modules

Execution graph

22 modules
mapMain

graph_out

`EntityChanges` emitted out for all the entities defined in the `schema.graphql` for the Uniswap v3 Subgraph.

from #12369621

Output

sf.substreams.entity.v1.EntityChanges

Inputs

sf.substreams.v1.Clockstore_pool_countstore_total_tx_countsstore_swaps_volumestore_derived_factory_tvlstore_eth_pricesmap_extract_data_typesmap_pools_createdstore_pool_sqrt_pricestore_pool_sqrt_pricestore_pool_liquiditiesstore_token_tvlstore_pricesstore_pricesstore_tokensstore_tokens_whitelist_poolsstore_derived_tvlstore_ticks_liquiditiesstore_total_tx_countsstore_eth_pricesstore_positionsstore_min_windowsstore_max_windows
map

map_extract_data_types

Chunky module which emits multiple types of `Events`. Looping over every transaction to filter out `Events`. For some events, we have to loop over `StorageChanges` to be able to fetch certain changes such as liquidity increases and decreases. For more information on what the `Event` contains, check proto/uniswap/v1/uniswap.proto. Try with ``` substreams gui substreams.yaml map_extract_data_types -t +1000 ```

from #12369621

Output

uniswap.types.v1.Events

Inputs

sf.ethereum.type.v2.Blockstore_pools_created
map

map_pools_created

This module will loop over block transactions and detect pools created events. Once the pool created events have been detected, `Pools` structs will be emitted out of the module. Try with ``` substreams gui substreams.yaml map_pools_created -t +1000 ```

from #12369621

Output

uniswap.types.v1.Pools

Inputs

sf.ethereum.type.v2.Block
map

map_tokens_whitelist_pools

This modules loops over the pools created and emits `ERC20Tokens` structs out of the module. Tokens part of the pair of a pool are checked against the `WHITELIST_TOKENS` constant to see if they are part of the list. If so push the address of the pool in the field `whitelist_pools` of the token. Try with ``` substreams gui substreams.yaml map_tokens_whitelist_pools -t +1000 ```

from #12369621

Output

uniswap.types.v1.ERC20Tokens

Inputs

map_pools_created
store

store_derived_factory_tvl

`BigDecimal` accumulator store for the derived `total_value_locked` in `USD`, `ETH`, `USDUntracked` and `ETHUntracked` for the factory.

from #12369621

Store value

bigdecimal

Update policy

add

Inputs

sf.substreams.v1.Clockstore_derived_tvl
store

store_eth_prices

`BigDecimal` setter store for the `eth_price`. This module uses a multiple stores and `map_extract_data_types` to find the `eth_price` of any given token. If a pool contains a token which has a pair with a _well-known_ token, the `eth_price` is easily found. Stores the USD price of ETH. For example: - Pool: DAI <> WBTC -> we check if there is a pool with DAI <> ETH and easily derive the price - Pool: ANYTOKEN0 <> DAI -> we can derive the price by finding the pool DAI <> ETH - Pool: ANYTOKEN0 <> ANYTOKEN1 -> more complicated case where we have to check on either side of the pool and try to find a path to reach a `whitelisted_token` which has a pool with ETH to be able to derive the price

from #12369621

Store value

bigdecimal

Update policy

set

Inputs

sf.substreams.v1.Clockmap_extract_data_typesstore_pools_createdstore_pricesstore_tokens_whitelist_poolsstore_native_amountsstore_pool_liquidities
store

store_max_windows

`BigDecimal` maximum store for the price of `eth` and token prices for `open` and `low` for daily and hourly.

from #12369621

Store value

bigdecimal

Update policy

max

Inputs

sf.substreams.v1.Clockstore_pricesstore_eth_prices
store

store_min_windows

`BigDecimal` minimum store for the price of `eth` and token prices for `open` and `low` for daily and hourly.

from #12369621

Store value

bigdecimal

Update policy

min

Inputs

sf.substreams.v1.Clockstore_pricesstore_eth_prices
store

store_native_amounts

`BigDecimal` setter store for the native amounts out of any `Event` type: `Mint`, `Swap` and `Burn` amounts (amount0 and amount1).

from #12369621

Store value

bigdecimal

Update policy

set

Inputs

map_extract_data_types
store

store_pool_count

`BigInt` store accumulator for each time a pool is created.

from #12369621

Store value

bigint

Update policy

add

Inputs

map_pools_created
store

store_pool_liquidities

`BigInt` store setter for storing pool liquidites which were extracted from `map_extract_data_types`.

from #12369621

Store value

bigint

Update policy

set

Inputs

sf.substreams.v1.Clockmap_extract_data_types
store

store_pools_created

This module stores the Pools emitted by the `map_pools_created` module. Dynamic data sources pattern for Uniswap v3 pools.

from #12369621

Store value

proto:uniswap.types.v1.Pool

Update policy

set

Inputs

map_pools_created
store

store_positions

`PositionEvent` setter store for `Position` Events emitted out of `map_extract_data_types`. `CreatedPosition`, `IncreaseLiquidityPosition`, `DecreaseLiquidityPosition`, `CollectPosition` and `TransferPosition` are stored.

from #12369621

Store value

proto:uniswap.types.v1.Events.PositionEvent

Update policy

set

Inputs

map_extract_data_types
store

store_prices

`BigDecimal` store setter for storing the price of token0 <> token1 and vice versa. Also store the Daily and Hourly prices. For example: Pool: TOKEN0 <> TOKEN1 - pool:{pool_address}:{token0_addr}:token0 -> 100 - pool:{pool_address}:{token1_addr}:token1 -> 1 This means that the price of TOKEN0 is 100 for 1 TOKEN1

from #12369621

Store value

bigdecimal

Update policy

set

Inputs

sf.substreams.v1.Clockmap_extract_data_typesstore_pools_created
store

store_swaps_volume

`BigDecimal` accumulator store for the swap volume of various entries such as `amount0_abs`, `amount1_abs`, `volume_usd`, `volume_usd_untracked`, `volume_eth`, `fee_usd` and `fee_eth`. The `_0` and `_1` entries are the value of one token for another token.

from #12369621

Store value

bigdecimal

Update policy

add

Inputs

sf.substreams.v1.Clockmap_extract_data_typesstore_pools_createdstore_total_tx_countsstore_eth_prices
store

store_ticks_liquidities

`BigInt` accumulator store for the liquidities of the pools. Tracking `liquidityGross` and `liquidityNet` for pool values at all times, daily and hourly for `Mint` and `Burn` events.

from #12369621

Store value

bigint

Update policy

add

Inputs

sf.substreams.v1.Clockmap_extract_data_types
store

store_token_tvl

`BigDecimal` accumulator store for the `total_value_locked` for tokens.

from #12369621

Store value

bigdecimal

Update policy

add

Inputs

map_extract_data_types
store

store_tokens

`Int64` store accumulator for each time a token is used for any combination for a pool.

from #12369621

Store value

int64

Update policy

add

Inputs

map_pools_created
store

store_tokens_whitelist_pools

`String` appender store which stores the `whitelist_pools` field of a token.

from #12369621

Store value

string

Update policy

append

Inputs

map_tokens_whitelist_pools
store

store_total_tx_counts

`BigInt` accumulator store for the total transaction counts for pools, tokens, factory, daily factory, daily and hourly for token and pool data.

from #12369621

Store value

bigint

Update policy

add

Inputs

sf.substreams.v1.Clockmap_extract_data_types
