uniswap_v4

Pinax

v0.2.4/2 downloads/Repository

Package ref

uniswap-v4@v0.2.4

Download .spkg

Run package

CLI

Run map_events from the command line.

substreams run uniswap-v4@v0.2.4 map_events -e mainnet --start-block -1

Authenticate by running substreams auth or directly on thegraph.market (see docs).

Modules

Execution graph

2 modules

mapMain

map_events

Output

uniswap.v4.Events

Inputs

sf.ethereum.type.v2.Block

store

store_pool

Store value

proto:uniswap.v4.StorePool

Update policy

set

Inputs

map_events

Protobuf

uniswap.v4

Eventsmain

uniswap.v4.Events

Transaction[]transactions = 1

Donate

uniswap.v4.Donate

/ @notice Emitted for donations / @param id The abi encoded hash of the pool key struct for the pool that was / donated to / @param sender The address that initiated the donate call / @param amount0 The amount donated in currency0 / @param amount1 The amount donated in currency1

bytesid = 1

address (Pool ID)

bytessender = 2

address

stringamount0 = 3

uint256

stringamount1 = 4

uint256

Initialize

uniswap.v4.Initialize

/ @notice Emitted when a new pool is initialized / @param id The abi encoded hash of the pool key struct for the new pool / @param currency0 The first currency of the pool by address sort order / @param currency1 The second currency of the pool by address sort order / @param fee The fee collected upon every swap in the pool, denominated in / hundredths of a bip / @param tickSpacing The minimum number of ticks between initialized ticks / @param hooks The hooks contract address for the pool, or address(0) if none / @param sqrtPriceX96 The price of the pool on initialization / @param tick The initial tick of the pool corresponding to the initialized / price

bytesid = 1

STORE primary key

bytescurrency0 = 2

address (token0)

bytescurrency1 = 3

address (token1)

uint64fee = 4

uint24 (e.g., 3000 represents 0.30%)

int32tick_spacing = 5

int24 (e.g., 60)

byteshooks = 6

address, or address(0) if none

stringsqrt_price_x96 = 7

uint160

int32tick = 8

int24

Log

uniswap.v4.Log

https://github.com/Uniswap/v4-core/blob/main/src/interfaces/IPoolManager.sol https://github.com/Uniswap/v4-core/blob/59d3ecf53afa9264a16bba0e38f4c5d2231f80bc/src/interfaces/IProtocolFees.sol

bytesaddress = 1

uint64ordinal = 2

bytes[]topics = 3

bytesdata = 4

Swapswap = 10oneof log

IPoolManager

Initializeinitialize = 11oneof log

ModifyLiquiditymodify_liquidity = 12oneof log

Donatedonate = 13oneof log

ProtocolFeeControllerUpdatedprotocol_fee_controller_updated = 14oneof log

IProtocolFees

ProtocolFeeUpdatedprotocol_fee_updated = 15oneof log

ModifyLiquidity

uniswap.v4.ModifyLiquidity

/ @notice Emitted when a liquidity position is modified / @param id The abi encoded hash of the pool key struct for the pool that was / modified / @param sender The address that modified the pool / @param tickLower The lower tick of the position / @param tickUpper The upper tick of the position / @param liquidityDelta The amount of liquidity that was added or removed / @param salt The extra data to make positions unique

bytesid = 1

address (Pool ID)

bytessender = 2

address

int32tick_lower = 3

int24

int32tick_upper = 4

int24

stringliquidity_delta = 5

int128

bytessalt = 6

bytes32

ProtocolFeeControllerUpdated

uniswap.v4.ProtocolFeeControllerUpdated

/ @notice Emitted when the protocol fee controller address is updated in / setProtocolFeeController.

bytesprotocol_fee_controller = 1

address

ProtocolFeeUpdated

uniswap.v4.ProtocolFeeUpdated

bytesid = 1

address (Pool ID)

uint64protocol_fee = 2

uint24

StorePool

uniswap.v4.StorePool

StorePool - minimal pool storage type Primary key: pool id

bytescurrency0 = 1

token0 address

bytescurrency1 = 2

token1 address

bytesfactory = 3

factory address that initialized the pool

Swap

uniswap.v4.Swap

/ @notice Emitted for swaps between currency0 and currency1 / @param id The abi encoded hash of the pool key struct for the pool that was / modified / @param sender The address that initiated the swap call, and that received / the callback / @param amount0 The delta of the currency0 balance of the pool / @param amount1 The delta of the currency1 balance of the pool / @param sqrtPriceX96 The sqrt(price) of the pool after the swap, as a Q64.96 / @param liquidity The liquidity of the pool after the swap / @param tick The log base 1.0001 of the price of the pool after the swap / @param fee The swap fee in hundredths of a bip

bytesid = 1

address (Pool ID)

bytessender = 2

address

stringamount0 = 3

int256

stringamount1 = 4

int256

stringsqrt_price_x96 = 5

uint160

stringliquidity = 6

uint128

int32tick = 7

int24

stringfee = 8

int256

Transaction

uniswap.v4.Transaction

byteshash = 1

bytesfrom = 2

bytesto = 3

uint64nonce = 5

stringgas_price = 6

uint256

uint64gas_limit = 7

uint64gas_used = 8

stringvalue = 9

uint256

Log[]logs = 10
