PancakeSwap V3 Substreams

Real-time block-aggregated swap data for PancakeSwap V3 across multiple blockchains.

Overview

This substreams package is specifically designed for PancakeSwap V3, which uses a different Swap event signature than Uniswap V3.

Supported networks:

• BNB Chain (BSC) - Primary PancakeSwap V3 deployment
• Ethereum - Cross-chain deployment
• Arbitrum - Layer 2 deployment
• zkSync Era - Layer 2 deployment
• Polygon zkEVM - Layer 2 deployment

Key Difference from Uniswap V3

PancakeSwap V3 uses an extended Swap event that includes protocol fee tracking:

Swap(address indexed sender, address indexed recipient, int256 amount0, int256 amount1, uint160 sqrtPriceX96, uint128 liquidity, int24 tick, uint128 protocolFeesToken0, uint128 protocolFeesToken1)

Event Signature Hash: 0x19b47279256b2a23a1665c810c8d55a1758940ee09377d4f8d26497a3577dc83

This is different from Uniswap V3's signature (0xc42079f94a6350d7e6235f29174924f928cc2ac818eb64fed8004e115fbcca67), which means a separate substreams package is required.

Network Configuration

The target network is specified at runtime via CLI parameters:

BNB Chain (BSC)

substreams run coinranking-pancakeswap-v3-v0.1.0.spkg map_v3_ticker_output \
  --substreams-endpoint="bsc.streamingfast.io:443" \
  --start-block=26324014

Ethereum Mainnet

substreams run coinranking-pancakeswap-v3-v0.1.0.spkg map_v3_ticker_output \
  --substreams-endpoint="mainnet.eth.streamingfast.io:443" \
  --start-block=16950686

Arbitrum One

substreams run coinranking-pancakeswap-v3-v0.1.0.spkg map_v3_ticker_output \
  --substreams-endpoint="arb-one.streamingfast.io:443" \
  --start-block=<TBD>

PancakeSwap V3 Deployment Blocks

Network	Deployment Block	Factory Address
BSC	26324014	0x0BFbCF9fa4f9C56B0F40a671Ad40E0805A091865
Ethereum	16950686	0x0BFbCF9fa4f9C56B0F40a671Ad40E0805A091865
Arbitrum	TBD	0x0BFbCF9fa4f9C56B0F40a671Ad40E0805A091865
zkSync Era	TBD	TBD
Polygon zkEVM	TBD	TBD

Module

map_v3_ticker_output

Aggregates swap data per pool per block, providing:

• Block volume for token0 and token1 (in raw token units)
• Number of swaps
• Closing price (calculated from sqrtPriceX96)
• Block number and timestamp

Output Format

This implementation outputs a TickerOutput message containing aggregated swap data for each pool that had activity in the block:

Volume Data

• Volumes are raw token units (not decimal-adjusted)
• Example: 500 USDC (6 decimals) is reported as "500000000"
• Consumers must divide by 10^decimals to get actual token amounts

Price Data

• Price is provided as sqrtPriceX96 - the raw value from swap events
• This is NOT a human-readable price
• Clients must calculate the actual price using:

  price = (sqrtPriceX96 / 2^96)^2 * 10^(token0_decimals - token1_decimals)


• The sqrtPriceX96 format is standard across all Uniswap V3 forks

Building

cargo build --release --target wasm32-unknown-unknown
substreams pack

Testing

Run the test script with any supported network:

./test.sh -s <start_block> -e <stop_block>

Requirements

• Substreams CLI
• Rust toolchain with wasm32-unknown-unknown target
• StreamingFast API token (get yours at https://app.streamingfast.io/)
